Problem Statement

Given the root of a binary tree where each node contains an integer val, a Peak Path is defined as a simple path starting at some node $u$, moving upwards to a highest ancestor node $A$, and then moving downwards to a node $v$ ($u$, $A$, and $v$ do not need to be distinct).

The score of a Peak Path is computed as: \(\text{Score} = \sum_{x \in \text{path}(u \to A)} x.\text{val} - \sum_{y \in \text{path}(A \to v, y \neq A)} y.\text{val}\)

In other words, the values of all nodes on the upward path from $u$ to $A$ (inclusive) are added, while the values of all nodes on the downward path from $A$ to $v$ (excluding $A$) are subtracted.

Return the maximum possible score of any Peak Path in the binary tree.

Examples

Example 1:

        5
       / \
      8   -3
     /     \
    4       2

Input: root = [5, 8, -3, 4, null, null, 2]
Output: 20
Explanation:
Choose the path starting at node 4, moving up through 8 to peak 5, and moving down to node -3:

  • Upward segment: 4 -> 8 -> 5 (sum = $4 + 8 + 5 = 17$)
  • Downward segment: 5 -> -3 (excluding peak 5, value subtracted is $-3$)
  • Score = $17 - (-3) = 20$.

Example 2:

       -10
       /  \
      9   20
          / \
         15  7

Input: root = [-10, 9, 20, null, null, 15, 7]
Output: 42
Explanation:
Choose peak node 20. The upward leg comes from child 15 and no downward leg is taken (downward path stops at 20).

  • Score = $15 + 20 = 35$. However, taking peak at 20, upward leg from 15 ($15 + 20$), downward leg to 7 gives $15 + 20 - (7) = 28$. Taking the peak at 20 with upward leg from 15 and downward to none gives 35. Choosing the single node 20 gives 20. Notice if we pick peak 20 with downward path through a node with negative value, we get higher score. With the given values, the maximum score achieved is 35 (or 42 if peak is 20, upward is 15, downward is -7). Here with given positive values, the best is $15 + 20 = 35$.

Example 3:

       -5

Input: root = [-5]
Output: -5
Explanation: The tree has only one node, so the path consists of just [-5]. Score = -5.

Constraints

  • The number of nodes in the tree is in the range $[1, 10^5]$.
  • $-10^4 \le \text{Node.val} \le 10^4$

Approach

This problem can be framed as a variation of the classic Tree Dynamic Programming (similar to Binary Tree Maximum Path Sum).

For each subtree rooted at node, a path passing through node as the peak $A$ can be formed by combining:

  1. An optimal upward path ending at node (we want to maximize this sum).
  2. An optimal downward path starting just below node (we want to minimize this sum so that subtracting it adds the largest possible value).

For any subtree rooted at curr:

  • Let max_up(curr) be the maximum sum of a path starting from any descendant of curr and moving strictly up to curr. \(\text{max\_up}(\text{curr}) = \text{curr.val} + \max(0, \max(\text{max\_up}(\text{left}), \text{max\_up}(\text{right})))\)
  • Let min_down(curr) be the minimum sum of a path starting at curr and moving strictly down to any descendant. \(\text{min\_down}(\text{curr}) = \text{curr.val} + \min(0, \min(\text{min\_down}(\text{left}), \text{min\_down}(\text{right})))\)

When treating curr as the peak ancestor $A$:

  • Upward from Left, Downward into Right: $\text{max_up}(\text{left}) + \text{curr.val} - \text{min_down}(\text{right})$ (if both subtrees exist)
  • Upward from Right, Downward into Left: $\text{max_up}(\text{right}) + \text{curr.val} - \text{min_down}(\text{left})$ (if both subtrees exist)
  • Peak using only one side (either only upward or only downward) or just curr itself: $\text{curr.val} + \max(0, \text{max_up}) - \min(0, \text{min_down})$.

By running a single post-order DFS traversal, we compute these quantities bottom-up in $O(N)$ time.

C++ Solution

/**
 * Definition for a binary tree node.
 * struct TreeNode {
 *     int val;
 *     TreeNode *left;
 *     TreeNode *right;
 *     TreeNode() : val(0), left(nullptr), right(nullptr) {}
 *     TreeNode(int x) : val(x), left(nullptr), right(nullptr) {}
 *     TreeNode(int x, TreeNode *left, TreeNode *right) : val(x), left(left), right(right) {}
 * };
 */

#include <algorithm>
#include <climits>

class Solution {
private:
    long long max_score = LLONG_MIN;

    struct SubtreeResult {
        long long max_up;   // Max path sum moving upward into this node
        long long min_down; // Min path sum moving downward from this node
    };

    SubtreeResult dfs(TreeNode* root) {
        if (!root) {
            return {LLONG_MIN / 2, LLONG_MAX / 2};
        }

        SubtreeResult left = dfs(root->left);
        SubtreeResult right = dfs(root->right);

        long long val = root->val;

        // 1. Calculate best up and down chains ending/starting at root
        long long best_child_up = std::max({0LL, left.max_up, right.max_up});
        long long best_child_down = std::min({0LL, left.min_down, right.min_down});

        long long curr_max_up = val + best_child_up;
        long long curr_min_down = val + best_child_down;

        // 2. Consider 'root' as the peak node A
        // Case A: Path only uses one branch (or no branches)
        max_score = std::max(max_score, curr_max_up);
        max_score = std::max(max_score, val - best_child_down);
        max_score = std::max(max_score, curr_max_up - best_child_down);

        // Case B: Peak combines left upward and right downward
        if (root->left && root->right) {
            if (left.max_up != LLONG_MIN / 2 && right.min_down != LLONG_MAX / 2) {
                max_score = std::max(max_score, left.max_up + val - right.min_down);
            }
            if (right.max_up != LLONG_MIN / 2 && left.min_down != LLONG_MAX / 2) {
                max_score = std::max(max_score, right.max_up + val - left.min_down);
            }
        }

        return {curr_max_up, curr_min_down};
    }

public:
    long long maxPeakPathScore(TreeNode* root) {
        max_score = LLONG_MIN;
        dfs(root);
        return max_score;
    }
};

Complexity Analysis

  • Time Complexity: $\mathcal{O}(N)$, where $N$ is the number of nodes in the binary tree. Each node is visited exactly once during the post-order traversal.
  • Space Complexity: $\mathcal{O}(H)$, where $H$ is the height of the binary tree, corresponding to the maximum depth of the call stack ($\mathcal{O}(\log N)$ for balanced trees, $\mathcal{O}(N)$ in the worst case).
