Problem Statement

You are an urban planner designing a sustainable energy grid for a city. You have been given a list of n rectangular solar panels to be installed on a flat 2D plane. Each solar panel is represented as rectangles[i] = [x1, y1, x2, y2], where (x1, y1) is the bottom-left corner and (x2, y2) is the top-right corner of the $i^{th}$ rectangle.

Since some solar panels may overlap, the total energy generated depends on the unique area covered by the union of all rectangles.

Return the total area covered by all rectangles in the plane. Since the answer may be very large, return it modulo $10^9 + 7$.

Examples

Example 1: Input: rectangles = [[0,0,2,2],[1,0,2,3],[1,0,3,1]]
Output: 6
Explanation:

  • The first rectangle covers the area from (0,0) to (2,2). (Area = 4)
  • The second rectangle covers (1,0) to (2,3). It adds the region (1,2) to (2,3). (Additional Area = 1)
  • The third rectangle covers (1,0) to (3,1). It adds the region (2,0) to (3,1). (Additional Area = 1)
  • Total unique area = 4 + 1 + 1 = 6.

Example 2: Input: rectangles = [[0,0,1000,1000],[500,500,1500,1500]]
Output: 1750000
Explanation:

  • Area of first: $1000 \times 1000 = 1,000,000$
  • Area of second: $1000 \times 1000 = 1,000,000$
  • Overlap area: $(1000-500) \times (1000-500) = 250,000$
  • Total: $1,000,000 + 1,000,000 - 250,000 = 1,750,000$.

Constraints

  • 1 <= rectangles.length <= 1000
  • rectangles[i].length == 4
  • 0 <= x1, y1, x2, y2 <= 10^9
  • x1 < x2 and y1 < y2

Approach

To solve this efficiently, we use a Line Sweep Algorithm. Instead of calculating the area of each rectangle and subtracting overlaps (which becomes complex with many rectangles), we imagine a vertical line sweeping from the leftmost x-coordinate to the rightmost x-coordinate.

  1. X-Coordinate Discretization: Collect all unique $x_1$ and $x_2$ coordinates from the input. Sort them. These sorted coordinates divide the plane into several vertical strips.
  2. Iterate Through Strips: For every interval between two consecutive sorted x-coordinates $[x_i, x_{i+1}]$:
    • The width of this strip is $\Delta x = x_{i+1} - x_i$.
    • If $\Delta x > 0$, we find all rectangles that cover this vertical strip (i.e., rectangles where $rect.x_1 \le x_i$ and $rect.x_2 \ge x_{i+1}$).
    • For these specific rectangles, we extract their y-intervals $[y_1, y_2]$.
  3. Merge Y-Intervals: Within the current strip, we need to find the total height covered by the union of these y-intervals.
    • Sort the y-intervals by their start points.
    • Merge them to find the total non-overlapping length $L$.
  4. Accumulate Area: The area contributed by this strip is $\Delta x \times L$. Add this to the total area modulo $10^9 + 7$.

Complexity Analysis:

  • Time Complexity: $O(N^2 \log N)$ where $N$ is the number of rectangles. There are at most $2N$ x-coordinates, and for each strip, we sort up to $N$ y-intervals.
  • Space Complexity: $O(N)$ to store the coordinates and intervals.

Implementation

#include <vector>
#include <algorithm>
#include <set>

using namespace std;

class Solution {
public:
    int totalCoverageArea(vector<vector<int>>& rectangles) {
        long long MOD = 1e9 + 7;
        set<int> x_set;
        for (const auto& r : rectangles) {
            x_set.insert(r[0]);
            x_set.insert(r[2]);
        }

        vector<int> sorted_x(x_set.begin(), x_set.end());
        long long total_area = 0;

        for (int i = 0; i < (int)sorted_x.size() - 1; ++i) {
            long long width = (long long)sorted_x[i+1] - sorted_x[i];
            if (width == 0) continue;

            // Find all y-intervals covering this x-strip
            vector<pair<int, int>> y_intervals;
            for (const auto& r : rectangles) {
                if (r[0] <= sorted_x[i] && r[2] >= sorted_x[i+1]) {
                    y_intervals.push_back({r[1], r[3]});
                }
            }

            if (y_intervals.empty()) continue;

            // Merge y-intervals to find total height
            sort(y_intervals.begin(), y_intervals.end());

            long long total_y_len = 0;
            int current_y_end = -1;

            for (const auto& interval : y_intervals) {
                int start = max(current_y_end, interval.first);
                if (interval.second > start) {
                    total_y_len += (interval.second - start);
                    current_y_end = interval.second;
                }
            }

            total_area = (total_area + (width * total_y_len)) % MOD;
        }

        return (int)total_area;
    }
};
