Problem Statement

You are given an array of $n$ points coordinates where coordinates[i] = [xi, yi] represents a vertex of a simple polygon. The vertices are given in order (either clockwise or counter-clockwise).

A simple polygon is a polygon that does not intersect itself and has no holes.

Your task is to find the number of points with integer coordinates that lie strictly inside the polygon.

Examples

Example 1: Input: coordinates = [[0,0], [3,0], [0,4]] Output: 3 Explanation: The vertices form a right triangle. The integer points on the boundary are (0,0), (1,0), (2,0), (3,0), (0,1), (0,2), (0,3), (0,4). The integer points strictly inside are (1,1), (1,2), and (2,1).

Example 2: Input: coordinates = [[0,0], [4,0], [4,4], [0,4]] Output: 9 Explanation: The vertices form a 4x4 square. The total number of integer points inside are (1,1), (1,2), (1,3), (2,1), (2,2), (2,3), (3,1), (3,2), and (3,3).

Constraints

  • 3 <= n <= 10^5
  • -10^6 <= xi, yi <= 10^6
  • The given points form a simple polygon.

Approach

To solve this problem, we combine two fundamental geometric principles: Shoelace Formula and Pick’s Theorem.

1. Shoelace Formula (Area of a Polygon)

The area $A$ of a simple polygon with vertices $(x_1, y_1), (x_2, y_2), \dots, (x_n, y_n)$ can be calculated using: \(2A = | \sum_{i=1}^{n} (x_i y_{i+1} - x_{i+1} y_i) |\) where $(x_{n+1}, y_{n+1}) = (x_1, y_1)$. Note that $2A$ will always be an integer if all vertices have integer coordinates.

2. Boundary Points

The number of integer points $B$ on a line segment connecting $(x_1, y_1)$ and $(x_2, y_2)$ is given by: \(\text{Points on segment} = \gcd(|x_2 - x_1|, |y_2 - y_1|) + 1\) To find the total boundary points $B$ of the polygon, we sum the $\gcd$ of the differences for every edge: \(B = \sum_{i=1}^{n} \gcd(|x_{i+1} - x_i|, |y_{i+1} - y_i|)\)

3. Pick’s Theorem

Pick’s Theorem relates the area $A$ of a polygon with integer vertices to the number of interior points $I$ and boundary points $B$: \(A = I + \frac{B}{2} - 1\) Rearranging for $I$ (the interior points): \(2I = 2A - B + 2 \implies I = \frac{2A - B + 2}{2}\)

Complexity Analysis

  • Time Complexity: $O(n \log(\max(coords)))$ due to the GCD calculation for each of the $n$ edges.
  • Space Complexity: $O(1)$ extra space if we ignore the input storage.

C++ Solution

#include <vector>
#include <numeric>
#include <cmath>

using namespace std;

class Solution {
public:
    /**
     * Calculates the number of integer points strictly inside a simple polygon.
     * Uses Shoelace Formula for Area and Pick's Theorem for interior points.
     */
    long long countInteriorPoints(vector<vector<int>>& coordinates) {
        int n = coordinates.size();
        long long doubleArea = 0;
        long long boundaryPoints = 0;

        for (int i = 0; i < n; ++i) {
            long long x1 = coordinates[i][0];
            long long y1 = coordinates[i][1];
            long long x2 = coordinates[(i + 1) % n][0];
            long long y2 = coordinates[(i + 1) % n][1];

            // 1. Shoelace Formula part: sum(x_i * y_{i+1} - x_{i+1} * y_i)
            doubleArea += (x1 * y2 - x2 * y1);

            // 2. Count boundary points on edge i -> i+1
            // The number of integer points on a segment is gcd(dx, dy)
            boundaryPoints += std::gcd(abs(x2 - x1), abs(y2 - y1));
        }

        // The area is half the absolute value of the shoelace sum
        if (doubleArea < 0) doubleArea = -doubleArea;

        // 3. Pick's Theorem: Area = Interior + (Boundary / 2) - 1
        // Multiplying by 2: 2 * Area = 2 * Interior + Boundary - 2
        // Therefore: 2 * Interior = 2 * Area - Boundary + 2
        long long interiorPoints = (doubleArea - boundaryPoints + 2) / 2;

        return interiorPoints;
    }
};
